Metric Plastic Flanged Sleeve Bearings For Packaging Machinery

Product Details:

Place of Origin:	CHINA
Brand Name:	OEM
Certification:	CUSN8,CUSN6.5 Bronze
Model Number:	PTFE PLAIN BEARINGS

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiation
Packaging Details:	Wooden cases standard export package
Delivery Time:	10-15 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000000 Piece/ per Month

Contact Now

Detailed Product Description

Name:	Plain Flanged Bearing	Material:	EPB A Thermal Mould Character Plastic
Application:	Packaging Machinery	Type:	Self-lubricating Bearings
Applications:	Office Machinery, Electronic Products	Certified:	CUSN8,CUSN6.5 Bronze
High Light:	CUSN8 Plastic Sleeve Bearing , CUSN6.5 Plastic Sleeve Bearing , Packaging Machinery Plastic Sleeve Bearing

Metric Plastic Flanged Sleeve Bearings For Packaging Machinery

Plastic Bearings & bushings Industry solutions | Plain Flanged bearing

EP plastic bearings and traditional oil bearing replace IGUS bushings plain bushings self-lubricating bearings

Plastic Compound Bearings Plain Bearings Metric Cylindrical Bushes EPB Sliding Bearings Black Lubricating Bushes

Material property sheet

Common Capability	Unit	EPT	EPG	EPH	EPX	EPJ	EPS
Density	g/cm³	1.46	1.46	1.65		1.49	1.24
Color		Black gray	Dark grey	Grey	Black	Yellow	Beige
Max.water absorption,23℃/ 50%	[% weight]	0.2	0.7	0.1		0.3	2.02
Max.water absorption	[% weight]	＜1.2	＜4	＜0.3	＜0.5	＜1.3	＜0.1
Dynamic friction /steel	μ	0.05-0.15	0.08-0.18	0.07-0.20	0.09-0.27	0.06-0.18	0.05-0.15
Max.PV(dry)	MPa•m/s	0.4	0.5	1.37	1.32	0.34	0.4
Mechanical behavior
E-module	MPa	2,300	7,800	12,500	8,100	2,400	830
Tensile strength,20℃	MPa	80	200	175	170	73	18
Compressive strength	MPa	65	80	90	150	35	10
Max.static pressure of the surface,20℃	MPa	35	80	150	90	20	10
Shore D hardness		70	112	87	85	74	73
Physical and thermal properties
Continuous work tempreature	℃	+80	+130	+200	+250	+90	+260
short-time work tempreature	℃	+120	+220	+240	+315	+120	+310
Minimum operating temperature	℃	-40	-40	-40	-100	-50	-200
Thermal conductivity	W/m•K	0.2	0.25	0.60	0.60	0.25	0.24
Max.water absorption,23℃	K-1•10-5	7	9	4	5	10	12
Conductivity
Volume resisticity	Ωcm	＞1012	＞1013	＜104	＜105	＞1013	＞1015
Surface resisticity	Ω	＞1015	＞1011	＜105	＜103	＞1012	＞1015

Characteristics

EP series of materials has excellent self-lubricating and wear resistance is mainly engineers take full advantage of the self-lubricating material modification technology, high-performance engineering plastics used in high-strength fiber to improve the material load and special grease reduced The friction coefficient of the material (Figure 1), thereby enhancing the comprehensive wear resistance of the material to extend the service life of the bearing. High-performance engineering plastics as the base material mainly as wear-resistant carrier; Reinforced fiber to improve the bearing in the bearing and impact resistance; Special grease reduces the coefficient of friction of the bearing from the role of lubrication.

Typical Applications

· Office Machinery
· Electronic Products
· Textile Machinery
· Fitness Machinery
· Agricultural Machinery
· Packaging Machinery
· Automotive Industry

Engineers are dedicated on the performance improvement on the self- lubricating materials derives the result that EP Series Materials are with excellent self- lubricating features and wear resistance Features. High- strength fibers used in the engineering plastics fantastically improve the material load (Graphl). Special grease immersion in the plastic can decrease the friction coefficient of the material therefore to proiong the bearing sevice life. High-performance engineering plastics body material mainly service as wear- resistant vector. The reinfoced fiber improves the load and impact resistant capacity of the beaing. Special grease decreases the fiction coefficient for a better selflubricating performance.

Multi Layered Bearings refer to plain bearings of thin walled with self-lubricating functions.
They are high performance, high quality, lubrication-free and maintenance-free bearings for various industries.
