| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | Bushing Standards Met: 83-7-7-3, ASTM B505, CDA 932, SAE 660 |
| Model Number: | Sleeve bearing type |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000000 Piece/ per Month |
| Name: | Sintered Bronze Bearings | Material: | Bronze Metal Powder |
|---|---|---|---|
| Type: | Sleeve, Flange,ring,split,Bushings | Shipment: | By Sea Or Air |
| Application: | Metal Sintered Fan Bushing | Feature: | Maintenance-free |
| High Light: | DN 200 Sintered Bronze Bushing,Oil Impregnated Sintered Bronze Bushing,DN 200 Sintered Bronze Bearings |
||
Sintered Bronze Bushes, Sintered Porous Metal Bearings The bush in Sintered Bronze give a wide range of applications, is realized with a powder of bronzesintered, calibrated and impregnated into specific oil
Oil impregnated is made of tin bronze powder mutallurgy, the bearing by increasing the porosity, oil containing rate be improved; it is long life because of high oil content, and abolition the oil filling felt, therefore, the total production cost reduced.
Bearing forms made to order: cylindrical bushes and flanged bushes with non-standard dimensions, spherical bearings, tubes and rod blanks, customized bearing designs
| SAE 841 Powdered Metal Bronze, Sleeve Bearing | |||||||||
| Specifications SAE841 SLEEVE Bearing Oil Impregnated Bronze | |||||||||
| Material Powdered Metal / Oil Impregnated Bronze | |||||||||
| Material Standard SAE 841 | |||||||||
| Tolerances | |||||||||
| Inner Diameter Tolerance +.000 -.001 in | |||||||||
| Outside Diameter Tolerance+.000 -.001 in | |||||||||
| Overall Length Tolerance .005 in | |||||||||
| Chemical Composition- Copper (87-90%), Tin (8-9), Iron (1.0% Max) Carbon (0.1%), other elements less than 0.1% | |||||||||
| MPIF: CT-1000-K26 | |||||||||
| ASTM: B438 Grade 1, Type 2 Class A | |||||||||
| SAE 841 - Bronze Mil-B-5687 Type 1, Grade 1 | |||||||||
| Ideal for heavy loads at moderate speeds or light loads at high speeds - max Pv 50,000, P-Load 2,000, V-SFM-1,200 | |||||||||
| Self-lubricating - when in motion oil rises to the surface for lubrication and restores itself when at rest. | |||||||||
| After forming, sintering and sizing, the bearings are vacuum impregnated with SAE 30 oil that provides lubricant which is metered from the bearing to the shaft during rotation. | |||||||||
| Standard off-the-shelf oil impregnated bronze bearings should function satisfactorily in temperatures ranging from 10F to 220F. | |||||||||
| RoHS, REACH, DFARS compliant |
· Do not need or only very little machining |
· High usage rate of material(more than 95%) |
· Parts size consistency is good and stable. The precision can reach 0.01mm. |
· The material composition can be adjusted according to the customers’requirement of the parts performance. |
· Do the treatment on the surface of the parts according to customers’ requirement to improve the strength and hardness. |
· Due to the die forming, we can customize the complex shape or special profiled parts which other machining can not do. |
· Because suitable for mass production, the production efficiency is high and the cost is lower than machining. |
