Name: Centrifugal Casting Plain Bush Bearing
Brand: Beijing Silk Road Enterprise Management Services Co.,LTD
SKU: BUSHING TYPE FLANGED PLAIN SLEEVE
Availability: InStock

Home Products Plain Bush Bearing

Centrifugal Casting Plain Bush Bearing

Product Details:

Place of Origin:	CHINA
Brand Name:	OEM
Certification:	DIN 1494, ISO 3547 STANDARD BUSHING
Model Number:	BUSHING TYPE FLANGED PLAIN SLEEVE

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiation
Packaging Details:	Wooden cases standard export package
Delivery Time:	10-15 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000000 Piece/ per Month

Contact Now

Detailed Product Description

Material:	CuZn25Al5Mn4Fe3	Characteristic:	Low-maintenance And Maintenance-free Plain Bearings
Type:	Bushes, Collar Bushes, Washers, Strips Or Special Designs	Size:	Standard Size Available
Density:	8g/cm3	Temp. Limits:	-40~+200℃
Max. Dynamic Load:	98N/mm²
Highlight:	DIN 1494 Plain Bush Bearing , 200℃ Plain Bush Bearing , 98N/mm² lain Bush Bearing

Centrifugal Casting Plain Bush Bearing

Our graphite bronze bushing can provide customers with a complete mechanical lubrication system. Our graphite is oil-less, self-lubricating, and designed for long life. This insures less down time and eliminates problems caused by high and low temperatures.

Material	CuZn25Al5Mn4Fe3
Typical Application	consecutive casting and rolling machines, mine-exploiting equipments, ships, steam engine, etc.
Density g/cm3	8
Hardness HB	>210
Tensile Strength N/mm²	>750
Yeild strength N/mm²	>340
Elongation %	>12
Coefficient of linear expansion 10-5/℃	2.2
Heat-conducting Coefficient W(/m.k)	38~55
Flexibility Coefficient KN/mm²	100~140
Temp. Limits ℃	-40~+200
Max. Dynamic Load N/mm²	98
Max.speed m/s	Dry Lubrication 0.3; Oil Lubrication 1.0
Max.PV N/mm²*m/s	Dry Lubrication 1.65; Oil Lubrication 3.25
Friction	Dry Lubrication 0.12~0.16; Oil Lubrication 0.03~0.08

Rolled Standard Profile

Cylindrical Sliding Bearings

Flanged Bushings

Thrust Washers

Strip Sections

Application area

self lubricatingbearing products are widely used in all industrial fields

Widely used in hydraulic and pneumatic industries, forging machine tool industry, plastics machinery industry, lifting and handling machinery, port machinery, office, fitness machinery, textile machinery, food packaging, filling machinery, chemical machinery, printing and packaging, paper making machinery, automobiles, railways Steam locomotives, shipbuilding industries, presses, metallurgical machinery, construction machinery, etc.

Self Lubricating Plain Bearing
